Mica (Standard)

Mica band heaters provide reliable surface heating for barrels and nozzles on injection molding and extrusion equipment. They offer thin-wall design for rapid response and efficient heat transfer in medium-temperature applications.

  • Operating Temp: 300°F to 900°F
  • Thin-wall design for fast response and efficient heat transfer
  • Commonly used on injection molding machines, extruders, packaging and food equipment
  • High dielectric strength mica insulation with rust-resistant plated sheath

Applications

  • Barrels of injection molding machines
  • Barrels of plastic extruders
  • Packaging machinery
  • Food processing equipment
  • Wire and cable production

Features

  • Easy to install
  • Thin wall for quick response to controls
  • Operates from 300°F to 900°F
  • Long service life under demanding conditions
  • Available in English and metric sizes

Design and Construction

  • Size: ID (minimum .75”), Width (minimum .5”)
  • Electrical: Watts, Volts- Ideal Watts per Square Inch 35 or less, 3 Phase
  • Lockup: Flange, Extended Flange, Strap, Key, Barrel Nut, Compression Springs, Quick Release Latch
  • Mechanical: Add Holes, Notches, Built in Thermocouple or Thermowell
  • Lead Options: Flexible Fiberglass Leads, Armored Cable (BX), Braided Wire
  • Other Power Supply Options: Screw Terminals (with or without ceramic caps), Plug, Housin
Applications
  • Barrels of injection molding machines
  • Barrels of plastic extruders
  • Packaging machinery
  • Food processing equipment
  • Wire and cable production
  • Easy to install
  • Thin wall for quick response to controls
  • Operates from 300°F to 900°F
  • Long service life under demanding conditions
  • Available in English and metric sizes
  • Size: ID (minimum .75”), Width (minimum .5”)
  • Electrical: Watts, Volts- Ideal Watts per Square Inch 35 or less, 3 Phase
  • Lockup: Flange, Extended Flange, Strap, Key, Barrel Nut, Compression Springs, Quick Release Latch
  • Mechanical: Add Holes, Notches, Built in Thermocouple or Thermowell
  • Lead Options: Flexible Fiberglass Leads, Armored Cable (BX), Braided Wire
  • Other Power Supply Options: Screw Terminals (with or without ceramic caps), Plug, Housin
